IAM2X122 — 12.2″ ARM Panel PC

12.2″ 1280 × 800 ARM Panel PC with an IP65 front bezel.

The IAM2X122 is a 12.2″ ARM Panel PC with a 1280 × 800 TFT LCD panel. It is available with single-point resistive or 10-point capacitive front options. It has an IP65 front bezel, an aluminium-magnesium alloy housing and a -20 to 70 °C operating range. Power input is 12–24 V DC. Mounting options are embedded, VESA. It runs on a Rockchip RK3568 ARM processor.
Request a quote Datasheet (PDF) (opens in a new tab)
IAM2X122 front view
In production

Technical specifications

15 specs
Technical specifications
Product
Product familyIAM2X
Display
Display Size12.2inches
Resolution1280 × 800
Panel TypeTFT LCD
Capacitive touchYes
Resistive touchYes
Processing
CPURockchip RK3568
Memory2GB
Technical specifications
Power
Input Voltage (min)12V DC
Input Voltage (max)24V DC
Environmental
Operating Temperature (min)-20°C
Operating Temperature (max)70°C
Ingress ProtectionIP65
Mechanical
Panel mountYes
VESA mountYes

Across the series

6 differences

Only the specifications that differ across this product line. Everything the models share is on the full specification table above.

Across the series
SpecificationIAM2X104IAM2X116IAM2X121This modelIAM2X122IAM2X150IAM2X156
DisplayDisplay Size10.4inches11.6inches12.1inches12.2inches15inches15.6inches
Resolution1024 × 7681920 × 10801024 × 7681280 × 8001024 × 7681366 × 768
EnvironmentalOperating Temperature (min)-30°C0°C-20°C-20°C-10°C0°C
Operating Temperature (max)80°C50°C70°C70°C65°C60°C
MechanicalPanel mount—YesYesYesYesYes
Wall mountYesYes————
